Description
FRAME
REACTO CF5 IV
material: carbon
700x30C max. wheelsize
100×12/ 142x12mm axle standard
BB86,5 bottom bracket standard
FORK
REACTO CF5 IV DISC
material: carbon
700x30C max. wheelsize
BRAKES
Shimano Dura Ace
Hydraulic disc
ROTORS
Shimano CL900
160mm
BRAKE LEVER
Shimano Dura Ace disc
HEADSET
FSA ACR
HANDLEBAR
Vision Metron 5D ACR EVO
material: carbon
380mm (3XS-XXS-XS-S)
400mm (M-L-XL)
HANDLEBAR STEM
Vision Metron 5D ACR EVO
material: carbon
90 mm (3XS/XXS/XS), 100 mm (S), 110 mm (M/L), 120 mm (XL)
GRIP
Prologo One-Touch
DERAILLEUR (F)
Shimano Dura Ace Di2
DERAILLEUR (R)
Shimano Dura Ace Di2
SHIFTERS
Shimano Dura Ace disc Di2
SEAT POST
MERIDA TEAM CW
Aero shape
15mm setback
Carbon
SEAT CLAMP
MERIDA REACTO Aero
SADDLE Prologo Scratch M5
V-mount adapter
incl. MERIDA minitool
CHAIN
Shimano M9100-12
CRANK
Shimano Dura Ace
52-36 teeth
Power Meter
165 mm-XXS, 170 mm-XS, 172.5 mm-S/M/L, 175 mm (XL)
FREEWHEEL
Shimano Dura-Ace R9200
11-30 teeth
12 speed
BOTTOM BRACKET
Shimano SM-BB72-41B
Pressfit 86.5
WHEELSET
Vision Metron 60 SL Clincher TL Disc
100x12mm width front hub
142x12mm width rear hub
21mm inner width
60mm height
Centerlock
material: carbon
Tubeless ready (tubeless tape and valves not included)
TYRE FRONT
Continental Grand Prix 5000S TR
700x28C
fold
tubeless ready
TYRE REAR
Continental Grand Prix 5000S TR
700x28C
fold
tubeless ready
AXLES
MERIDA EXPERT SL
APPROX. WEIGHT
7.6 kg
MAX. WEIGHT
120 kg
To reduce production and delivery times the supplier sometimes have to make last-minute changes to product specifications. These updates may not always be reflected in the product descriptions or images on our website.
