Harris Alloy 26 Aluminum SMAW Welding Electrode

Description

Harris® 26 aluminum alloy electrode features a precise combination of core alloy and coating, providing high speed deposition of dense, machinable welds. It is widely used on sheets, tubes and extrusions. Also suited for torch applications.

• Harris® Alloy 26 aluminum stick (SMAW) electrode 3/32 x 14 in. x 4 ea. tube/box POP
• Harris® 26 aluminum alloy electrode features a precise combination of core alloy and coating, providing high speed deposition of dense, machinable welds. It is widely used on sheets, tubes and extrusions. Also suited for torch applications.
• Produces strong, porosity-free welds without excessive spatter or fuming
• Precise combination of cored wire and coating, providing high speed deposition of dense welds
• Good corrosion resistance
• Good electrical conductivity
• Silver color is a good match to aluminum
• On heavy sections, joints should be beveled to form a 60◦ to 75◦ vee
• Pre-heat heavy sections to 500◦F (260◦C) to flatten bead and reduce amount of amperage required
• Widely used on sheet metals, tubes and extrusions for thicknesses of 1/8 in. (3.2 mm) or more
• Typical applications include joining aluminum alloys (sheets, plates, castings and extrusions) with thicknesses of 1/8 in. (3.18mm) or more
• Used on torch applications
• Harris® Alloy 26 aluminum Stick (SMAW) electrode 3/32 x 14 in. x 4 ea. tube/box POP
• 1 Year
• Harris® 26
• Harris
• StickSMAW

• Alloy Type: Specialty
• Chemical Composition: Aluminum Fluoride 1-11%;Magnesium 0.05% max.;Copper 0.40% max.;Manganese 0.05% max.;Lithium Fluoride 1-11%;Silicon 1-11%;Zinc 0.10% max.;Magnesium Fluoride 1-11%;Iron 0.80% max.;Potassium Chloride 1-11%;Potassium Fluoride 2-12%;Sodium Chloride 1-11%;Aluminum Remainder%
• Classification: Manufactured to Harris Products Group’s internal engineering standards
• Color: Silver color is a good match to aluminum
• Diameter: 3/32 in (2.4 mm)
• Electrical Conductivity (%IACS): Good
• Material: Aluminum
• NSF Compliant: No
• RoHS Compliant: No
• Size: 4 ea. tube
• Tensile Strength (PSI): 34000
• Typical Application: Joining aluminum alloys such as sheets, plates, castings and extrusions with a thickness of 1/8 in. or more.

What’s Included: Harris® Alloy 26 aluminum Stick (SMAW) electrode 3/32 x 14 in. x 4 ea. tube/box POP

Model Name: Harris® 26
